Recycling Bale Clamp T413RC

with independent sideshift - with cylinder- and sideshift protection - 2 hydraulic functions

Datasheet as pdf Find a contact person Call technical data

Specification:

KAUP Recycling Bale Clamps are suitable for the transportation of non- palletised reusable materials in the recycling industry. This special range of bale clamps has several specific features, e.g. clamping arms 2 metres long for clamping the load, strengthened arm connections on the clamp profiles to allow clamping with the tips of the arms.

Product pictures and videos

Qualities:

Excellent price-performance ratio
Solid strengthened design with KAUP clamp profiles from T-profiles and C-profiles
Strengthened arm construction with toothed bars
Solid wear and tear bars under clamp body and clamp arms optionally
Independent sideshift serially
Combination with KAUP rotary devices possible
Customer specified modifications feasible

Also available without sideshift, model T403RC
Load Backrest see model T179.

Attachment has separate sideshift as standard. The maximum allowable sideshift stroke (e.g. ± 100 mm) is always available independent of fork or arm position (with clamps or fork positioners).

Attachment is operated hydraulically, i.e. supplied with oil from the forklift truck’s hydraulic system. Truck requires two additional hydraulic functions.

Attachment serially equipped with cylinder and sideshift protection.

Attachment can be fitted with load backrest model T479. The load backrest model T479.1 is suitable for fork positioners T160B and T466B up to 4.8T.

Attachment is designed with toe-in on the tips which should be taken into account when choosing the opening range.
