Rotating Tyre Clamp T458BR

Rotation 360° endless - short arm hydraulically adjustable in each turning position (BCT = fixed) - continuous contact pad - 2 hydraulic functions

Datasheet as pdf Find a contact person

Technical data

Specification:

The new view-optimised designed KAUP Rotating Tyre Clamp T458BR is predestined for the transport of several tyres at the same size. The short clamp arm is hydraulically adjustable under a rotary corner of 45°, so a concentric load admission can be guaranteed with this role clamp.

Qualities:

  • Very good visibility conditions
  • Favourable lost load and weight
  • Solid, slender arm construction
  • Rotation 360° endlessly
  • Limitation on rotation 180° optionally
  • Artificial positive rake optionally
  • Service friendly
  • BCR Version with fixed short arm.
  • Capacity related to max. roll diameter.
  • Optional: The short arm can be hydraulically adjusted at a rotation angle of 45°.
  • All models available restricted to 180°.
  • For taking up horizontal rolls, 5-degree mast forward tilt is required.
  • Pressure plate coverings see under accessories.
  • Attachment with sideshift Model T498BR/T498BCR (add-on price).
Your KAUP consultant
André Christ

Product details

Attachment rotates hydraulically by 360° endless in both directions.
Attachment is operated hydraulically, i.e. supplied with oil from the forklift truck’s hydraulic system. Truck requires two additional hydraulic functions.
Attachment is serially designed without sideshift. It can be fitted with separate or valveblock sidesift upon request.
Attachment can be fitted with different types of contact pad surfaces specifically suited to the application.
Attachment is available restricted to 180° rotation.
